Lead-halide perovskites have demonstrated astonishing increases in power conversion efficiency in photovoltaics over the last decade. The most efficient perovskite devices now outperform industry-standard multi-crystalline silicon solar cells, despite the fact that perovskites are typically grown at low temperature using simple solution-based methods. However, the toxicity of lead and its ready solubility in water are concerns for widespread implementation. These challenges, alongside the many successes of the perovskites, have motivated significant efforts across multiple disciplines to find lead-free and stable alternatives which could mimic the ability of the perovskites to achieve high performance with low temperature, facile fabrication methods. This Review discusses the computational and experimental approaches that have been taken to discover lead-free perovskite-inspired materials, and the recent successes and challenges in synthesizing these compounds. The atomistic origins of the extraordinary performance exhibited by lead-halide perovskites in photovoltaic devices is discussed, alongside the key challenges in engineering such high-performance in alternative, next-generation materials. Beyond photovoltaics, this Review discusses the impact perovskite-inspired materials have had in spurring efforts to apply new materials in other optoelectronic applications, namely light-emitting diodes, photocatalysts, radiation detectors, thin film transistors and memristors. Finally, the prospects and key challenges faced by the field in advancing the development of perovskite-inspired materials towards realization in commercial devices is discussed.

Recent progress in artificial intelligence is largely attributed to the rapid development of machine learning, especially in the algorithm and neural network models. However, it is the performance of the hardware, in particular the energy efficiency of a computing system that sets the fundamental limit of the capability of machine learning. Data-centric computing requires a revolution in hardware systems, since traditional digital computers based on transistors and the von Neumann architecture were not purposely designed for neuromorphic computing. A hardware platform based on emerging devices and new architecture is the hope for future computing with dramatically improved throughput and energy efficiency. Building such a system, nevertheless, faces a number of challenges, ranging from materials selection, device optimization, circuit fabrication and system integration, to name a few. The aim of this Roadmap is to present a snapshot of emerging hardware technologies that are potentially beneficial for machine learning, providing the Nanotechnology readers with a perspective of challenges and opportunities in this burgeoning field.

Quantum phenomena are typically observable at length and time scales smaller than those of our everyday experience, often involving individual particles or excitations. The past few decades have seen a revolution in the ability to structure matter at the nanoscale, and experiments at the single particle level have become commonplace. This has opened wide new avenues for exploring and harnessing quantum mechanical effects in condensed matter. These quantum phenomena, in turn, have the potential to revolutionize the way we communicate, compute and probe the nanoscale world. Here, we review developments in key areas of quantum research in light of the nanotechnologies that enable them, with a view to what the future holds. Materials and devices with nanoscale features are used for quantum metrology and sensing, as building blocks for quantum computing, and as sources and detectors for quantum communication. They enable explorations of quantum behaviour and unconventional states in nano- and opto-mechanical systems, low-dimensional systems, molecular devices, nano-plasmonics, quantum electrodynamics, scanning tunnelling microscopy, and more. This rapidly expanding intersection of nanotechnology and quantum science/technology is mutually beneficial to both fields, laying claim to some of the most exciting scientific leaps of the last decade, with more on the horizon.

Batteries are commonly considered one of the key technologies to reduce carbon dioxide emissions caused by the transport, power, and industry sectors. We need to remember that not only the production of energy needs to be realized sustainably, but also the technologies for energy storage need to follow the green guidelines to reduce the emission of greenhouse gases effectively. To reach the sustainability goals, we have to make batteries with the performances beyond their present capabilities concerning their lifetime, reliability, and safety. To be commercially viable, the technologies, materials, and chemicals utilized in batteries must support scalability that enables cost-effective large-scale production.

As lithium-ion battery (LIB) is still the prevailing technology of the rechargeable batteries for the next ten years, the most practical approach to obtain batteries with better performance is to develop the chemistry and materials utilized in LIBs—especially in terms of safety and commercialization. To this end, silicon is the most promising candidate to obtain ultra-high performance on the anode side of the cell as silicon gives the highest theoretical capacity of the anode exceeding ten times the one of graphite. By balancing the other components in the cell, it is realistic to increase the overall capacity of the battery by 100%–200%. However, the exploitation of silicon in LIBs is anything else than a simple task due to the severe material-related challenges caused by lithiation/delithiation during battery cycling. The present review makes a comprehensive overview of the latest studies focusing on the utilization of nanosized silicon as the anode material in LIBs.

Artificial intelligence (AI) has the ability of revolutionizing our lives and society in a radical way, by enabling machine learning in the industry, business, health, transportation, and many other fields. The ability to recognize objects, faces, and speech, requires, however, exceptional computational power and time, which is conflicting with the current difficulties in transistor scaling due to physical and architectural limitations. As a result, to accelerate the progress of AI, it is necessary to develop materials, devices, and systems that closely mimic the human brain. In this work, we review the current status and challenges on the emerging neuromorphic devices for brain-inspired computing. First, we provide an overview of the memory device technologies which have been proposed for synapse and neuron circuits in neuromorphic systems. Then, we describe the implementation of synaptic learning in the two main types of neural networks, namely the deep neural network and the spiking neural network (SNN). Bio-inspired learning, such as the spike-timing dependent plasticity scheme, is shown to enable unsupervised learning processes which are typical of the human brain. Hardware implementations of SNNs for the recognition of spatial and spatio-temporal patterns are also shown to support the cognitive computation in silico. Finally, we explore the recent advances in reproducing bio-neural processes via device physics, such as insulating-metal transitions, nanoionics drift/diffusion, and magnetization flipping in spintronic devices. By harnessing the device physics in emerging materials, neuromorphic engineering with advanced functionality, higher density and better energy efficiency can be developed.

This roadmap on Nanotechnology for Catalysis and Solar Energy Conversion focuses on the application of nanotechnology in addressing the current challenges of energy conversion: ‘high efficiency, stability, safety, and the potential for low-cost/scalable manufacturing’ to quote from the contributed article by Nathan Lewis. This roadmap focuses on solar-to-fuel conversion, solar water splitting, solar photovoltaics and bio-catalysis. It includes dye-sensitized solar cells (DSSCs), perovskite solar cells, and organic photovoltaics. Smart engineering of colloidal quantum materials and nanostructured electrodes will improve solar-to-fuel conversion efficiency, as described in the articles by Waiskopf and Banin and Meyer. Semiconductor nanoparticles will also improve solar energy conversion efficiency, as discussed by Boschloo et al in their article on DSSCs. Perovskite solar cells have advanced rapidly in recent years, including new ideas on 2D and 3D hybrid halide perovskites, as described by Spanopoulos et al ‘Next generation’ solar cells using multiple exciton generation (MEG) from hot carriers, described in the article by Nozik and Beard, could lead to remarkable improvement in photovoltaic efficiency by using quantization effects in semiconductor nanostructures (quantum dots, wires or wells). These challenges will not be met without simultaneous improvement in nanoscale characterization methods. Terahertz spectroscopy, discussed in the article by Milot et al is one example of a method that is overcoming the difficulties associated with nanoscale materials characterization by avoiding electrical contacts to nanoparticles, allowing characterization during device operation, and enabling characterization of a single nanoparticle. Besides experimental advances, computational science is also meeting the challenges of nanomaterials synthesis. The article by Kohlstedt and Schatz discusses the computational frameworks being used to predict structure–property relationships in materials and devices, including machine learning methods, with an emphasis on organic photovoltaics. The contribution by Megarity and Armstrong presents the ‘electrochemical leaf’ for improvements in electrochemistry and beyond. In addition, biohybrid approaches can take advantage of efficient and specific enzyme catalysts. These articles present the nanoscience and technology at the forefront of renewable energy development that will have significant benefits to society.

Resistive switching (RS) devices are promising forms of non-volatile memory. However, one of the biggest challenges for RS memory applications is the device-to-device (D2D) variability, which is related to the intrinsic stochastic formation and configuration of oxygen vacancy (V _O) conductive filaments (CFs). In order to reduce the D2D variability, control over the formation and configuration of oxygen vacancies is paramount. In this study, we report on the Zr doping of TaO _x -based RS devices prepared by pulsed-laser deposition as an efficient means of reducing the V _O formation energy and increasing the confinement of CFs, thus reducing D2D variability. Our findings were supported by XPS, spectroscopic ellipsometry and electronic transport analysis. Zr-doped films showed increased V _O concentration and more localized V _Os, due to the interaction with Zr. DC and pulse mode electrical characterization showed that the D2D variability was decreased by a factor of seven, the resistance window was doubled, and a more gradual and monotonic long-term potentiation/depression in pulse switching was achieved in forming-free Zr:TaO _x devices, thus displaying promising performance for artificial synapse applications.

Integrating layered two-dimensional (2D) materials into 3D heterostructures offers opportunities for novel material functionalities and applications in electronics and photonics. In order to build the highest quality heterostructures, it is crucial to preserve the cleanliness and morphology of 2D material surfaces that come in contact with polymers such as PDMS during transfer. Here we report that substantial residues and up to ∼0.22% compressive strain can be present in monolayer MoS ₂ transferred using PDMS. We show that a UV-ozone pre-cleaning of the PDMS surface before exfoliation significantly reduces organic residues on transferred MoS ₂ flakes. An additional 200 ^◦C vacuum anneal after transfer efficiently removes interfacial bubbles and wrinkles as well as accumulated strain, thereby restoring the surface morphology of transferred flakes to their native state. Our recipe is important for building clean heterostructures of 2D materials and increasing the reproducibility and reliability of devices based on them.

Background. The development of dental caries is associated with various microorganisms and secondary caries formation is the main cause of restorations failure. The advice for restorative dental materials that have antimicrobial properties has stimulated the introduction of materials containing different antibacterial agents. Objectives. The present study has been designed to synthesize silver nanoparticles (AgNPs) and incorporate AgNPs and amoxicillin into glass ionomer cement (GIC) to synergize its effect on oral microbes. The effect of the added antimicrobial agents on compressive strength (CS) of GIC was also evaluated. Material and methods. Biosynthesis of AgNPs was done using Cupressus macrocarpa extract and AgNPs were characterized. A total of 120 disc-shaped specimens were prepared and classified into 4 main groups where Group A includes conventional GIC, Groups B and C include GIC with AgNPs or amoxicillin, respectively, while Group D included GIC with both AgNPs and amoxicillin. Each group was tested for the antimicrobial activity against both Streptococcus mutans ( S. mutans) and Staphylococcus aureus ( S. aureus). The distribution of biofilm was examined via a scanning electron microscope. The CS of the tested material was measured using a Material Test System. Results. The UV−visible spectrum showed a peak of 429 nm. Transmission electron microscopy, x-ray diffraction pattern and Fourier transform infrared analysis confirmed the formation of AgNPs with spherical to oblong polydispersed particles of diameter in the range of 13.5–25.8 nm. The maximum inhibitory zone was recorded for group D against both tested bacteria with a mean of 29 mm at first 24 h period to 15 mm at three weeks and showed antimicrobial rate 92.2% and 92.56%, against both strains, respectively. Additionally, group D disintegrated the structure of S. aureus biofilm and even kill bacteria in the biofilms. The addition of AgNPs and amoxicillin caused an insignificant effect on CS of GIC. Conclusion. TheAgNPs showed a synergistic effect in combination with amoxicillin and GIC dental restorative material against studied microorganisms. The agents can be safely added with minimal effect on the mechanical properties of the original cement.

Zinc oxide (ZnO) is an adaptable material that has distinctive properties, such as high-sensitivity, large specific area, non-toxicity, good compatibility and a high isoelectric point, which favours it to be considered with a few exceptions. It is the most desirable group of nanostructure as far as both structure and properties. The unique and tuneable properties of nanostructured ZnO shows excellent stability in chemically as well as thermally stable n-type semiconducting material with wide applications such as in luminescent material, supercapacitors, battery, solar cells, photocatalysis, biosensors, biomedical and biological applications in the form of bulk crystal, thin film and pellets. The nanosized materials exhibit higher dissolution rates as well as higher solubility when compared to the bulk materials. This review significantly focused on the current improvement in ZnO-based nanomaterials/composites/doped materials for the application in the field of energy storage and conversion devices and biological applications. Special deliberation has been paid on supercapacitors, Li-ion batteries, dye-sensitized solar cells, photocatalysis, biosensors, biomedical and biological applications. Finally, the benefits of ZnO-based materials for the utilizations in the field of energy and biological sciences are moreover consistently analysed.

Nanomaterials, in addition to their small size, possess unique physicochemical properties that differ from bulk materials, making them ideal for a host of novel applications. Magnetic nanoparticles (MNPs) are one important class of nanomaterials that have been widely studied for their potential applications in nanomedicine. Due to the fact that MNPs can be detected and manipulated by remote magnetic fields, it opens a wide opportunity for them to be used in vivo. Nowadays, MNPs have been used for diverse applications including magnetic biosensing (diagnostics), magnetic imaging, magnetic separation, drug and gene delivery, and hyperthermia therapy, etc. Specifically, we reviewed some emerging techniques in magnetic diagnostics such as magnetoresistive (MR) and micro-Hall ( μHall) biosensors, as well as the magnetic particle spectroscopy, magnetic relaxation switching and surface enhanced Raman spectroscopy (SERS)-based bioassays. Recent advances in applying MNPs as contrast agents in magnetic resonance imaging and as tracer materials in magnetic particle imaging are reviewed. In addition, the development of high magnetic moment MNPs with proper surface functionalization has progressed exponentially over the past decade. To this end, different MNP synthesis approaches and surface coating strategies are reviewed and the biocompatibility and toxicity of surface functionalized MNP nanocomposites are also discussed. Herein, we are aiming to provide a comprehensive assessment of the state-of-the-art biological and biomedical applications of MNPs. This review is not only to provide in-depth insights into the different synthesis, biofunctionalization, biosensing, imaging, and therapy methods but also to give an overview of limitations and possibilities of each technology.

Here, we demonstrate a microwave (MW) cavity interference enhancement method to image nano-defects on the surface of metal waveguide. The MW cavity interference system mainly consisted of a MW coaxial resonant cavity with a nano-probe. The MW signals have been evenly divided into two channels. One was the reference signal inputted into the MW waveguide and coupled into the MW cavity via the probe. Also, the coupling strength depends on the distance between the probe and the MW waveguide. Another one was directly inputted the MW cavity to interfere with the reference signal, and was enhanced in the cavity. Then, the surface topography of the metal waveguide was mapped by calculating the enhanced signals. In our experiment, a weak signal of ∼1 pW coupled from the waveguide can be detected by a MW cavity with the quality factor of ∼209. As a proof of application, the topography of nano-defects on the surface of metal waveguide in an MW chip has been mapped with a resolution of ∼15 nm. We have proved that this is a high-resolution, easy-to-manufacture, low-cost, and real-time online monitoring approach for online assessment and screening chips. This potentially has broad applications in the fields of chip manufacturing, chip inspection, nano-structure detection, and so on.

The catalytic reduction of nitro compounds is currently a hot research area, how to efficiently and stably degrade such toxic and harmful substances has become the research goal of many researchers. In this work, an Artemia cyst shell (ACS)–TiO ₂–MoS ₂ ternary porous structure was proposed and prepared as a catalyst for the reduction of 2-nitroaniline (2-NA) and 4-nitrophenol (4-NP). The ACS has a large number of porous structures, exhibits a good binding ability with TiO ₂ and MoS ₂, and provides a large number of active sites for the catalytic reduction process. The obtained composite material has a good reduction effect on 4-NP and 2-NA, with a good stability and recyclability, which is obviously higher than the reduction effect of ACS–TiO ₂ and MoS ₂ under the same conditions. This work provides ideas for the design of porous catalytic materials.

Artificial intelligence (AI) has the ability of revolutionizing our lives and society in a radical way, by enabling machine learning in the industry, business, health, transportation, and many other fields. The ability to recognize objects, faces, and speech, requires, however, exceptional computational power and time, which is conflicting with the current difficulties in transistor scaling due to physical and architectural limitations. As a result, to accelerate the progress of AI, it is necessary to develop materials, devices, and systems that closely mimic the human brain. In this work, we review the current status and challenges on the emerging neuromorphic devices for brain-inspired computing. First, we provide an overview of the memory device technologies which have been proposed for synapse and neuron circuits in neuromorphic systems. Then, we describe the implementation of synaptic learning in the two main types of neural networks, namely the deep neural network and the spiking neural network (SNN). Bio-inspired learning, such as the spike-timing dependent plasticity scheme, is shown to enable unsupervised learning processes which are typical of the human brain. Hardware implementations of SNNs for the recognition of spatial and spatio-temporal patterns are also shown to support the cognitive computation in silico. Finally, we explore the recent advances in reproducing bio-neural processes via device physics, such as insulating-metal transitions, nanoionics drift/diffusion, and magnetization flipping in spintronic devices. By harnessing the device physics in emerging materials, neuromorphic engineering with advanced functionality, higher density and better energy efficiency can be developed.

Colorful indoor organic photovoltaics (OPVs) have attracted considerable attention in recent years for their autonomous function in internet-of-things (IoT) devices. In this study, a solution-processed TiO₂ layer in a metal–oxide–metal (MOM) color filter electrode is used for light energy recycling in P3HT:ICBA-based indoor OPVs. The MOM electrode allows for tuning of the optical cavity mode to maximize photocurrent production by modulating the thickness of the TiO₂ layer in the sandwich structure. This approach preserves the OPVs' optoelectronic properties without damaging the photoactive layer and enables them to display a suitable range of vivid colors. The optimized MOM-OPVs demonstrated an excellent power conversion efficiency (PCE) of 8.8% ± 0.2%, which is approximately 20% higher than that of reference opaque OPVs under 1000 lx light emitting diode illumination. This can be attributed to the high photocurrent density due to the nonresonant light reflected from metals into the photoactive layer. Additionally, the proposed MOM-OPVs exhibited high external quantum efficiency and large parasitic shunt resistances, leading to improved fill factor and PCE values. Thus, the study's MOM electrode provides excellent feasibility for realizing colorful and efficient indoor OPVs for IoT applications.

The synergistic effects involving surface adsorption and photocatalytic degradation commonly play significant roles in the removal of persistent synthetic organics from wastewater in the case of porous semiconductors. Inspired by the visible-light harvesting advantages of porphyrin-based MOFs, a capsule-like bimetallic porphyrin-based MOF (PCN-222(Ni/Hf)) has been successfully constructed through a facile hydrothermal method. In which, the Hf (IV) ions were exactly bonded to the carboxyl groups substituted on the porphyrin rings, meanwhile the Ni (II) ions were finely bonded to the −N inside the porphyrin rings. The adsorption/photocatalytic performances were assessed by using four persistent dyes including rhodamine B (RhB), basic violet 14 (BV14), crystal violet, and acid black 210 (AB210) as the target substances, and enhanced total removal efficiency was obtained by the bimetallic PCN-222(Ni/Hf) in comparison with that of single PCN-222(Hf). The electrochemical analyses and the sacrificial agent capture experiments were carried out to elucidate the photocatalytic mechanism, and the adsorption/photocatalytic stability of PCN-222(Ni/Hf) is also investigated. The work has broadened the applications of porphyrin-based MOFs in the removal of organics by combining their excellent surface adsorption capacity and photocatalytic activities.

Germanium diselenide (GeSe₂) has emerged as a new member of anisotropic two-dimensional (2D) materials and gained increasing attention because of its excellent air stability, wide band gap and unique anisotropic properties, which exhibits promising applications in the fields of electronics, optoelectronics and polarized photodetection. However, the controllable epitaxial growth of large-scale and high-quality GeSe₂ nanostructures to date remains a big challenge. Herein, GeSe₂ nanofilms with lateral size up to centimeter scale have been successfully prepared on mica substrate by employing chemical vapor deposition technique. Experimental results demonstrated that hydrogen is the key factor for the controllable growth of GeSe₂ nanostructures and GeSe₂-based heterostructures. Corresponding growth mechanism was proposed based on systematical characterizations. The nonlinear optical properties of as-prepared GeSe₂ were investigated by employing open-aperture z-scan technique exhibiting significant saturable and reverse saturable absorption behaviors at wavelengths of 400 nm and 800 nm, respectively. This study provides a new and robust route for fabricating GeSe₂ nanostructures and 2D heterostructures, which will benefit the development of GeSe₂-based nonlinear optical and optoelectronic devices.

Enclosed silver nanoloops have unique features in manipulating and controlling light. However, even the conception of their growth mechanism has not been established. The intermediate structure at the growth stage were revealed as the crucial issue for studying their smart growth mechanism of silver nanoloops and nanowires. Early growth stage showed that silver nanorods and nanoparticles were grown in their respective polyvinylpyrrolidone micelles. Then, the silver nanorods and nanoparticles were assembled in a rod–particle–rod pattern via micelle–micelle coupling, forming linear silver nanowires. These silver nanowires were attracted by Van der Waals forces forming the initial nanoloop. Notably, there was a silver nanoparticle between the ends of two adjacent nanowires. This silver nanoparticle acted like solder and played a crucial role in connecting the two adjacent nanowires; consequently, a silver nanoloop was formed. This finding also suggested that similar smart growth patterns might exist for other one-dimensional and looped nanomaterials.

The use of nanoparticles is one of the strategies currently studied to minimize the toxicity and lack of tissue specificity of many cancer drugs used in chemotherapy. In this research the physicochemical and biological behavior of a novel self-assembled nanostructure of the antibiotic Teicoplanin (Teico) was characterized as a nanocarrier system for solubilizing highly hydrophobic drugs like Paclitaxel (Ptx) in aqueous media. The Teico micelles were loaded with Ptx in DMSO or PEG-400. The interaction between the loaded micelles and Albumin human serum albumin (HSA) was then studied by size exclusion chromatography. Transmission electron microscopy, dynamic light scattering and high-resolution liquid chromatography were also used to characterize the physicochemical and structural properties of the micelles to form the Teico/Ptx and Teico/Ptx/HSA micelles. Cellular uptake of Ptx was evaluated by fluorescent microscopy. The in vitro cytotoxicity of the complexes was studied on Hep-2 tumor cells, by a Crystal Violet assay. Teico cosolvent-free micelles can solubilize up to 20 mg.ml⁻¹ of Ptx dissolved in PEG, increasing four times the solubility of Ptx in water compared to Abraxane, and 20 000 times the intrinsic solubility of Ptx in water. In addition, Teico/Ptx micelles binds spontaneously HSA through hydrophobic interaction. Teico and Teico/HSA micelles as a Ptx transporter does not affect its release or biological activity. Therefore, Teico/Ptx or Teico/Ptx/HSA complexes appear as new alternatives for transporting larger amounts of hydrophobic drugs that offer advantages, turning it an interesting option for further study.

Nano- and microstructures of silicon (Si) exhibit electric and magnetic Mie resonances in the optical regime, providing a novel platform for controlling light at the nanoscale and enhancing light–matter interactions. In this Review, we present recent development of colloidal Si nanoparticles (NPs) that have wide range of applications in nanophotonics. Following brief summary of synthesis methods of amorphous and crystalline Si particles with high sphericity, optical responses of single Si particles placed on a substrate are overviewed. Then, the capability as a nanoantenna to control light–matter interactions is discussed in different systems. Finally, collective optical responses of Si NPs in solution are presented and the application potentials are discussed.

Carbon nanofibers (CNFs) exhibit the advantages of high mechanical strength, good conductivity, easy production, and low cost, which have shown wide applications in the fields of materials science, nanotechnology, biomedicine, tissue engineering, sensors, wearable electronics, and other aspects. To promote the applications of CNF-based nanomaterials in wearable devices, the flexibility, electronic conductivity, thickness, weight, and bio-safety of CNF-based films/membranes are crucial. In this review, we present recent advances in the fabrication of CNF-based composite nanomaterials for flexible wearable devices. For this aim, firstly we introduce the synthesis and functionalization of CNFs, which promote the optimization of physical, chemical, and biological properties of CNFs. Then, the fabrication of two-dimensional and three-dimensional CNF-based materials are demonstrated. In addition, enhanced electric, mechanical, optical, magnetic, and biological properties of CNFs through the hybridization with other functional nanomaterials by synergistic effects are presented and discussed. Finally, wearable applications of CNF-based materials for flexible batteries, supercapacitors, strain/piezoresistive sensors, bio-signal detectors, and electromagnetic interference shielding devices are introduced and discussed in detail. We believe that this work will be beneficial for readers and researchers to understand both structural and functional tailoring of CNFs, and to design and fabricate novel CNF-based flexible and wearable devices for advanced applications.

Transmission x-ray microscopy (TXM), which can provide morphological and chemical structural information inside of battery component materials at tens of nanometer scale, has become a powerful tool in battery research. This article presents a short review of the TXM, including its instrumentation, battery research applications, and the practical sample preparation and data analysis in the TXM applications. A brief discussion on the challenges and opportunities in the TXM applications is presented at the end.

Ti ₃C ₂T _x is an important member of the MXenes family. Due to its excellent electrical conductivity, adjustable atomic layer, and modifiable active surface, Ti ₃C ₂T _x has attracted great attention in the field of electromagnetic interference (EMI) shielding. This paper introduces the important role of regulating conductive network to improve the EMI shielding performance of materials and summarizes the EMI shielding performance of Ti ₃C ₂T _x nanohybrids reported in recent years. In addition, Ti ₃C ₂T _x based EMI shielding materials towards multifunctional devices are also systematically introduced. After that, the development status of Ti ₃C ₂T _x nanohybrids in the field of EMI shielding is objectively described, and the main problems and challenges are evaluated. Finally, the prospect of Ti ₃C ₂T _x nanohybrids for advanced and green EMI shielding materials is forecasted.

Nanodiamond (ND) synthesis by nanosecond laser irradiation has sparked tremendous scientific and technological interest. This review describes efforts to obtain cost-effective ND synthesis from polymers and carbon nanotubes (CNT) by the melting route. For polymers, ultraviolet (UV) irradiation triggers intricate photothermal and photochemical processes that result in photochemical degradation, subsequently generating an amorphous carbon film; this process is followed by melting and undercooling of the carbon film at rates exceeding 10 ⁹ K s ⁻¹. Multiple laser shots increase the absorption coefficient of PTFE, resulting in the growth of ⟨110⟩ oriented ND film. Multiple laser shots on CNTs result in pseudo topotactic diamond growth to form a diamond fiber. This technique is useful for fabricating 4–50 nm sized NDs. These NDs can further be employed as seed materials that are used in bulk epitaxial growth of microdiamonds using chemical vapor deposition, particularly for use with non-lattice matched substrates that formerly did not form continuous and adherent films. We also provide insights into biocompatible precursors for ND synthesis such as polybenzimidazole fiber. ND fabrication by UV irradiation of graphitic and polymeric carbon opens up a pathway for preparing selective coatings of polymer-diamond composites, doped nanodiamonds, and graphene composites for quantum computing and biomedical applications.

Purpose. To overcome the insufficiency of conventional photodynamic therapy (PDT) for treating metastatic melanoma, the combination of smart nanoparticles and PDT with immunotherapy was used to achieve a higher efficiency by accumulating more photosensitizers in tumor areas and triggering stronger immune responses against tumors after PDT. Methods. In this study, we designed a nanoliposome co-encapsulation of chlorin E6 (Ce6) and SB-3CT to realize significant antitumoral proliferation and metastasis efficacy after laser irradiation in A375 cells. The morphology, size distribution, and loading efficiency of Ce6–SB3CT@Liposome (Lip-SC) were characterized. The reactive oxygen species (ROS) generation and cytotoxicity were evaluated in A375 cells, and the mechanisms of natural killer (NK) cell-mediated killing were assessed. Results. Lip-SC showed good stability and was well-dispersed with a diameter of approximately 140 nm in phosphate-buffered saline. The nanoliposomes could accumulate in tumor areas and induce apoptosis in cancer cells upon 660 nm light irradiation, which could trigger an immune response and induce the expression of NK group 2 member D (NKG2D) ligands. The subsequently released SB-3CT could further activate NK cells effectively and strengthen the immune system by inhibiting the shedding of soluble NKG2D ligands. Discussion. Taken together, the synergistic effects of SB-3CT on nanoliposomes for Ce6-mediated PDT were analyzed in detail to provide a new platform for future anti-melanoma treatment.

In this work, we present a novel force-sensing device with zinc oxide nanorods (ZnO NRs) integrated with a metal-oxide-semiconductor (MOS) capacitor and encapsulated with Kapton tape. The details of the fabrication process and working principle of the integrated ZnO NRs-MOS capacitor as a force sensor and nanogenerator have been discussed. The fabricated ZnO-MOS device is tested for both the open-circuit and resistor-connected mode. For an input force in the range of 1–32 N, the open-circuit output voltage of the device is measured to be in the range of 60–100 mV for different device configurations. In the resistor-connected mode, the maximum output power of 0.6 pW is obtained with a 1 MΩ external resistor and input force of 8 N. In addition, the influence of different seed layers (Ag and ZnO) and the patterning geometry of the ZnO nanorods on the output voltage of ZnO-MOS device have been investigated by experiments. An equivalent circuit model of the device has been developed to study the influence of the geometry of ZnO NRs and Kapton tape on the ZnO-MOS device voltage output. This study could be an example of integrating piezoelectric nanomaterials on traditional electronic devices and could inspire novel designs and fabrication methods for nanoscale self-powered force sensors and nanogenerators.

Transmission x-ray microscopy (TXM), which can provide morphological and chemical structural information inside of battery component materials at tens of nanometer scale, has become a powerful tool in battery research. This article presents a short review of the TXM, including its instrumentation, battery research applications, and the practical sample preparation and data analysis in the TXM applications. A brief discussion on the challenges and opportunities in the TXM applications is presented at the end.

Fractional charges can be induced by magnetic fluxes at the interface between a topological insulator (TI) and a type-II superconductor due to axion electrodynamics. In a Josephson junction array with a hole in the middle, these electronic states can have phase interference in an applied magnetic field with period, in addition to the 2 π interference of the Cooper pairs. Here, we test an experimental configuration for probing the fractional charge and report the observation of phase interference effect in superconducting arrays with a hole in the middle in both Au- and TI-based devices. Our numerical simulations based on resistive shunted capacitive junction model are in good agreement with the experimental results. However, no clear sign of an axion charge-related interference effect was observed. We will discuss possible reasons and perspectives for future experiments.

Ga _x In _{(1− x)}P nanowires with suitable bandgap (1.35–2.26 eV) ranging from the visible to near-infrared wavelength have great potential in optoelectronic applications. Due to the large surface-to-volume ratio of nanowires, the surface states become a pronounced factor affecting device performance. In this work, we performed a systematic study of Ga _x In _{(1− x)}P nanowires’ surface passivation, utilizing Al _y In _{(1− y)}P shells grown in situ by using a metal-organic vapor phase epitaxy system. Time-resolved photoinduced luminescence and time-resolved THz spectroscopy measurements were performed to study the nanowires’ carrier recombination processes. Compared to the bare Ga _0.41In _0.59P nanowires without shells, the hole and electron lifetime of the nanowires with the Al _0.36In _0.64P shells are found to be larger by 40 and 1.1 times, respectively, demonstrating effective surface passivation of trap states. When shells with higher Al composition were grown, both lifetimes of free holes and electrons decreased prominently. We attribute the acceleration of PL decay to an increase in the trap states’ density due to the formation of defects, including the polycrystalline and oxidized amorphous areas in these samples. Furthermore, in a separate set of samples, we varied the shell thickness. We observed that a certain shell thickness of approximately ∼20 nm is needed for efficient passivation of Ga _0.31In _0.69P nanowires. The photoconductivity of the sample with a shell thickness of 23 nm decays 10 times slower compared with that of the bare core nanowires. We concluded that both the hole and electron trapping and the overall charge recombination in Ga _x In _{(1− x)}P nanowires can be substantially passivated through growing an Al _y In _{(1− y)}P shell with appropriate Al composition and thickness. Therefore, we have developed an effective in situ surface passivation of Ga _x In _{(1− x)}P nanowires by use of Al _y In _{(1− y)}P shells, paving the way to high-performance Ga _x In _{(1− x)}P nanowires optoelectronic devices.

The discovery of ferroelectricity in the fluorite structure based hafnium oxide (HfO ₂) material sparked major efforts for reviving the ferroelectric field effect transistor (FeFET) memory concept. A Novel metal-ferroelectric-metal-ferroelectric-insulator-semiconductor (MFMFIS) FeFET memory is reported based on dual ferroelectric integration as an MFM and MFIS in a single gate stack using Si-doped Hafnium oxide (HSO) ferroelectric (FE) material. The MFMFIS top and bottom electrode contacts, dual HSO based ferroelectric layers, and tailored MFM to MFIS area ratio (AR-TB) provide a flexible stack structure tuning for improving the FeFET performance. The AR-TB tuning shows a tradeoff between the MFM voltage increase and the weaker FET Si channel inversion, particularly notable in the drain saturation current I _D(sat) when the AR-TB ratio decreases. Dual HSO ferroelectric layer integration enables a maximized memory window (MW) and dynamic control of its size by tuning the MFM to MFIS switching contribution through the AR-TB change. The stack structure control via the AR-TB tuning shows further merits in terms of a low voltage switching for a saturated MW size, an extremely linear at wide dynamic range of the current update, as well as high symmetry in the long term synaptic potentiation and depression. The MFMFIS stack reliability is reported in terms of the switching variability, temperature dependence, endurance, and retention. The MFMFIS concept is thoroughly discussed revealing profound insights on the optimal MFMFIS stack structure control for enhancing the FeFET memory performance.

Resistive switching (RS) devices are promising forms of non-volatile memory. However, one of the biggest challenges for RS memory applications is the device-to-device (D2D) variability, which is related to the intrinsic stochastic formation and configuration of oxygen vacancy (V _O) conductive filaments (CFs). In order to reduce the D2D variability, control over the formation and configuration of oxygen vacancies is paramount. In this study, we report on the Zr doping of TaO _x -based RS devices prepared by pulsed-laser deposition as an efficient means of reducing the V _O formation energy and increasing the confinement of CFs, thus reducing D2D variability. Our findings were supported by XPS, spectroscopic ellipsometry and electronic transport analysis. Zr-doped films showed increased V _O concentration and more localized V _Os, due to the interaction with Zr. DC and pulse mode electrical characterization showed that the D2D variability was decreased by a factor of seven, the resistance window was doubled, and a more gradual and monotonic long-term potentiation/depression in pulse switching was achieved in forming-free Zr:TaO _x devices, thus displaying promising performance for artificial synapse applications.

Currently, a single treatment is less effective for triple-negative breast cancer (TNBC) therapy. Additionally, there are some limitations to the use of siRNA alone as a new method to treat breast cancer, such as its effective delivery into cells. In this study, we proposed a strategy that combines a siRNA-loaded DNA nanostructure and genistein for TNBC therapy. Both CD36 siRNA-loaded self-assembled DNA nanoprisms (NP-siCD36) and genistein knocked down CD36, resulting in enhanced anticancer efficacy through phosphorylation of the p38 MAPK pathway. In vitro studies showed that combination therapy could effectively enhance cell apoptosis and reduce cell proliferation, achieving an antitumor effect in TNBC cells. The current study suggests that NP-siCD36 combined with genistein might be a promising strategy for breast cancer and treatment.

Spark ablation, a versatile, gas-phase physical nanoparticle synthesis method was employed to fabricate fiber-optic surface enhanced Raman scattering (SERS) sensors in a simple single-step process. We demonstrate that spark-generated silver nanoparticles can be simply deposited onto a fiber tip by means of a modified low-pressure inertial impactor, thus providing significant surface enhancement for fiber-based Raman measurements. The surface morphology of the produced sensors was characterized along with the estimation of the enhancement factor and the inter- and intra-experimental variation of the measured Raman spectrum as well as the investigation of the concentration dependence of the SERS signal. The electric field enhancement over the deposited silver nanostructure was simulated in order to facilitate the better understanding of the performance of the fabricated SERS sensors. A potential application in the continuous monitoring of a target molecule was demonstrated on a simple model system.

This work investigates the effect of an in situ hydrogen plasma treatment on gate bias stability and performance of amorphous InGaZnO thin-film transistors (TFTs) deposited by using atmospheric-pressure PECVD. The H ₂ plasma-treated a-IGZO channel has shown significant improvement in bias stress induced instability with a minuscule threshold voltage shift (Δ V _th) of 0.31 and −0.17 V under positive gate bias stress (PBS) and negative gate bias stress (NBS), respectively. With the aid of the energy band diagram, the proposed work demonstrates the formation of negative species O ₂ ⁻ and positive species H ₂O ⁺ in the backchannel under PBS and NBS in addition to ionized oxygen vacancy (V _o) defects at a-IGZO/ZrO ₂ interfaces are the reason for gate bias instability which could be effectively suppressed with in situ H ₂ plasma treatment. From the experimental result, it is observed that the electrical performance such as field-effect mobility ( μ _FE), on-off current ratio ( I _on/ I _off), and subthreshold swing improved significantly by in situ H ₂ plasma treatment with passivation of interface trap density and bulk trap defects.
