Periodic Repeating Fast Radio Bursts: Interaction between a Magnetized Neutron Star and Its Planet in an Eccentric Orbit

The first discovery of fast radio bursts (FRBs) by Lorimer et al. (2007) and consequent reports of five similar sources by Keane et al. (2012) and Thornton et al. (2013) opened a new window in astronomy. Since then FRBs have become an active topic for research. The isotropic energy released by FRBs is in the range of 10³⁸–10⁴⁶ erg, and their duration is typically several milliseconds. The observed dispersion measure is ∼110–2596 pc cm⁻³ (Petroff et al. 2019), which strongly hints that FRBs are of cosmological origin. According to the observed repeatability (Petroff et al. 2015), these enigmatic events may come from two kinds of progenitors, i.e., repeating sources and nonrepeating sources.

Many models (see Platts et al. 2019 for a recent review) have been proposed to interpret the properties of FRBs. However, their underlying physics—the progenitor as well as emission mechanism—remains unclear (Katz 2018; Cordes & Chatterjee 2019; Petroff et al. 2019; Platts et al. 2019; Zhang 2020). Repeating FRBs, in particular periodic repeating FRBs, may provide valuable information about the nature of this mysterious phenomenon.

Here we will mainly focus on the periodic repeating activities of FRBs. The most famous periodic repeating sources are FRB 121102 and FRB 180916. FRB 121102 has a period of 157 days (Rajwade et al. 2020), and FRB 180916 has a period of 16.35 days (Chime/Frb Collaboration et al. 2020). Two kinds of models, the single-star model and binary model, have been proposed to interpret the periodic repeatability of these FRBs. The single-star models are mainly concerned with the precession of neutron stars (NSs; Levin et al. 2020; Sob'yanin 2020; Yang & Zou 2020; Zanazzi & Lai 2020), while the binary models associate FRBs with the interaction between the two objects in NS binary systems (Mottez & Zarka 2014; Dai et al. 2016; Zhang 2017, 2018; Dai 2020; Dai & Zhong 2020; Geng et al. 2020; Gu et al. 2020; Ioka & Zhang 2020; Lyutikov et al. 2020; Mottez et al. 2020; Decoene et al. 2021; Du et al. 2021). Usually, the precession period of a NS is unlikely to be as long as 16.35 days (Chime/Frb Collaboration et al. 2020). Additionally, the fixed emission region of FRBs in the precession models has not yet been properly addressed (Xiao et al. 2021). Various observational facts imply that binary models are more likely favored by the periodicity of FRBs. The binary-interaction models can be further categorized into two main classes: wind-like models and accretion/collision-like models. The wind-like models include the binary comb mechanism (Zhang 2017, 2018; Ioka & Zhang 2020), mild pulsars in tight O/B-star binaries (Lyutikov et al. 2020), small bodies orbiting around a pulsar or a magnetar (Mottez & Zarka 2014; Mottez et al. 2020; Voisin et al. 2021), and Kozai–Lidov feeding of NSs in binary systems (Decoene et al. 2021). The accretion/collision-like models include the collision between a magnetized NS and an asteroid belt (Dai et al. 2016; Smallwood et al. 2019; Dai 2020; Dai & Zhong 2020), accretion of strange stars from low-mass companion stars (Geng et al. 2021), and NS–white dwarf (WD) interactions (Gu et al. 2016, 2020). FRBs and their counterparts in other wavelengths have been studied by Yang & Zhang (2021), Yang (2021), and by many other authors. As suggested earlier by a few authors, collisions between small bodies and a NS can generate transient events such as gamma-ray bursts (Campana et al. 2011), glitch/antiglitches and X-ray bursts (Huang & Geng 2014; Yu & Huang 2016), and FRBs (Geng & Huang 2015; Dai et al. 2016).

Tidal disruption of minor planets/asteroids around WDs has also been extensively studied (Bear & Soker 2013; Vanderburg et al. 2015; Granvik et al. 2016). Recent simulations (Malamud & Perets 2020a, 2020b) have shown that a planet in a highly eccentric orbit around a WD could be tidally disrupted by tidal force, and materials in the inner side of the orbit would be accreted by the WD. Accreted clumps of such materials may be responsible for the pollution of a WD's atmosphere by heavy elements (Vanderburg et al. 2015; Malamud & Perets 2020a, 2020b). Similar processes (disruption of a planet) can also occur in NS–planet systems if the initial parameters of the planetary system fulfill the tidal disruption condition (Brook et al. 2014). In fact, GRB 101225A may occur in this way (Campana et al. 2011). Much efforts have also been made to search for close-in exoplanets around pulsars (Geng & Huang 2015; Huang & Yu 2017; Kuerban et al. 2020).

In this study, we propose a new model to explain the periodic repeating properties of FRB sources. We argue that when a planet is in a highly eccentric orbit around a NS, it would be partially disrupted every time it passes through the pericenter. The major fragments generated during the disruption will interact with the pulsar (rotating NS) wind to produce a series of FRBs. This model can naturally explain the periodic behavior of repeating FRBs. The structure of our paper is as follows. In Section 2, we present the basic framework of our model for repeating FRBs. In Section 3, the wind–clump interaction mechanism for FRBs is introduced. In Section 4, the periodicity and active window are described in view of the model. In Section 5, we estimate the evaporation timescale for a planet in an elliptical orbit. In Section 6, we address the possible existence of pulsar planets in highly eccentric orbits. Finally, Section 7 presents our conclusions and some brief discussion.

The planet-disruption interpretation for the pollution of a WD's atmosphere by heavy elements (Vanderburg et al. 2015; Granvik et al. 2016; Stephan et al. 2017; Malamud & Perets 2020a, 2020b) and the Alfvén wing theory for FRBs (Mottez & Zarka 2014; Mottez et al. 2020) motivates us to investigate the periodic repeating activities of FRBs in the framework of a NS–planet interaction model. When a planet is in an highly elliptical orbit with the periastron distance being small enough, it might be partially disrupted every time it passes through the pericenter. The disrupted fragments formed during this process will regularly interact with the host NS and produce periodic repeating FRBs.

Figure 1 illustrates the general picture of a NS–planet system in an eccentric orbit. We assume that the central star is a NS with a mass M_⋆ = 1.4 M_⊙, and the companion is a rocky planet with a mass m, mean density $\bar{\rho }$, and an orbital period P_orb. The semimajor axis (a) and orbital period are related by the Kepler's third law as

$$\begin{eqnarray}&&\displaystyle \frac{{P}_{\mathrm{orb}}^{2}}{{a}^{3}}=\displaystyle \frac{4{\pi }^{2}}{G({M}_{\star }+m)}.\end{eqnarray} \tag{ 1 }$$

The distance between the NS and planet at phase θ (the true anomaly; see Figure 1) in the eccentric orbit is

$$\begin{eqnarray}&&r=\displaystyle \frac{a(1-{e}^{2})}{1+e\,\cos \theta },\end{eqnarray} \tag{ 2 }$$

where e is the eccentricity of the orbit. The characteristic tidal disruption radius of the planet depends on its density as (Hills 1975)

$$\begin{eqnarray}&&{r}_{\mathrm{td}}\approx {\left(\displaystyle \frac{6{M}_{\star }}{\pi \,\bar{\rho }}\right)}^{1/3}.\end{eqnarray} \tag{ 3 }$$

Zoom In Zoom Out Reset image size

Whether a planet will be tidally disrupted or not depends on its separation (r) with respect to the NS. If r is smaller than a critical value of 2.7 r_td, then it will begin to be partially disrupted (Liu et al. 2013). The separation between the planet and NS is different when the planet is at different orbital phase. At periastron, it is

$$\begin{eqnarray}&&{r}_{{\rm{p}}}=a(1-e).\end{eqnarray} \tag{ 4 }$$

For a highly elliptical orbit on which the separation varies in a very wide range, the planet may be tidally affected mainly near the periastron and it is relatively safe at other orbital phases. Here, we focus on the disruption near the periastron. If the orbit is too compact (for example, r_p ≤ r_td), then the disruption is violent and the planet will be completely destroyed. However, when r_td < r_p < 2.7 r_td, then the planet will only be partially disrupted every time it passes by the periastron. Since the density at the surface is relatively small, the outer crust of the planet will be destroyed first, which gives birth to a number of fragments with the size of a few kilometers. The main portion of the planet will retain its integrity. The idea of partial disruption has been supported both from observations (Manser et al. 2019) and simulations (Liu et al. 2013; Malamud & Perets 2020a, 2020b).

In our study, we assume r_p = 2 r_td for simplicity, which satisfies the condition for a partial disruption. We can then calculate the relation between the periastron distance and the orbital period, which depends on the orbital eccentricity. The results are shown in Figure 2. For comparison, we have also marked the partial tidal disruption distance (2 r_td for the planet with a particular density) as horizontal lines. We can see that a partial disruption would occur near the periastron for a wide range of orbital periods. For example, for an orbit with e = 0.95, the partially disrupted planet will have an orbital period of ∼20 days when its mean density is 30 g cm⁻³. If the mean density is 10 g cm⁻³, 5 g cm⁻³, or 3 g cm⁻³, then the orbital period will be 30 days, 43 days, and 60 days, correspondingly. More generally, for a planet with a mean density ranging from 3 to 10 g cm⁻³, partial disruption will occur for P_orb ∼ 2–600 days when the eccentricity is e ∼ 0.5–0.99. Note that the mass of the planet does not affect the disruption too much. The disruption process is mainly determined by orbital parameters and the mean density of the planet.

Zoom In Zoom Out Reset image size

A number of fragments will be generated during the partial disruption process. These fragments will experience some complicated dynamical interactions such as gravitational perturbation (Naoz 2016, see below) and scattering/collision (Cordes & Shannon 2008). These interactions lead the clumps to orbit around the central NS with slightly different orbital parameters (velocity, semimajor axis, eccentricity, inclination relative to the planet's orbit, etc.). In the orbiting process, the interaction between the clumps and the pulsar wind can generate FRBs through the Alfvén wing mechanism (Mottez & Zarka 2014; Mottez et al. 2020).

The above process of partial disruption happens periodically every time the surviving main portion of the planet passes through the periastron. Consequently, this regular interaction can account for the periodic repeating FRBs.

Orbiting small bodies immersed in the relativistic wind of a highly magnetized pulsar can be the sources of repeating FRBs (Mottez & Zarka 2014; Mottez et al. 2020). The interaction between the small body and the pulsar wind produces a small Alfvén wing angle (see Table 1 in Mottez & Zarka 2014). When the wind plasma crosses the Alfvén wing, it sees a rotation of the ambient magnetic field that can cause radio wave instabilities. In the observer's reference frame, the radiation is focused into a very small solid angle due to the relativistic beaming effect, which amplifies the flux density and produces FRBs. At a distance of ∼1 au from the pulsar, the required size for a small body to produce FRBs is a few kilometers.

When a pulsar with a surface magnetic field B_⋆ and angular frequency Ω_⋆ interacts with a small body of size R_c, it generates an Alfvén wing with a power of (Mottez & Heyvaerts 2020)

$$\begin{eqnarray}&&{\dot{E}}_{{\rm{A}}}=\displaystyle \frac{\pi }{{\mu }_{0}{c}^{3}}{B}_{\star }^{2}{R}_{\star }^{6}{{\rm{\Omega }}}_{\star }^{4}{R}_{{\rm{c}}}^{2}{r}^{-2},\end{eqnarray} \tag{ 5 }$$

where μ₀ is the magnetic conductivity, c is the speed of light, R_⋆ is the radius of the pulsar, r is the separation between the two objects and is a function of θ as shown in Equation (2). The radio emission power of the Alfvén wing is

$$\begin{eqnarray}&&{\dot{E}}_{\mathrm{radio}}={\epsilon }_{{\rm{r}}}{\dot{E}}_{{\rm{A}}},\end{eqnarray} \tag{ 6 }$$

where 2 × 10⁻³ ≤ _r ≤ 10⁻² is the radiation efficiency (Zarka et al. 2001; Zarka 2007). In the observer's reference frame, the radio flux density generated from the interaction between the pulsar wind and a small sized object is (Mottez et al. 2020)

$$\begin{eqnarray}\begin{array}{rcl}\left(\displaystyle \frac{S}{\mathrm{Jy}}\right) & = & 2.7\times {10}^{-9}{A}_{\mathrm{cone}}{\left(\displaystyle \frac{\gamma }{{10}^{5}}\right)}^{2}\left(\displaystyle \frac{{\epsilon }_{{\rm{r}}}}{{10}^{-3}}\right)\\ & & \times \,{\left(\displaystyle \frac{{R}_{{\rm{c}}}}{{10}^{9}\ \mathrm{cm}}\right)}^{2}{\left(\displaystyle \frac{r}{\mathrm{au}}\right)}^{-2}{\left(\displaystyle \frac{{R}_{\star }}{{10}^{6}\ \mathrm{cm}}\right)}^{6}{\left(\displaystyle \frac{{B}_{\star }}{{10}^{9}\ {\rm{G}}}\right)}^{2}\\ & & \times \,{\left(\displaystyle \frac{{P}_{\star }}{{10}^{-2}\,{\rm{s}}}\right)}^{-4}{\left(\displaystyle \frac{D}{1\ \mathrm{Gpc}}\right)}^{-2}{\left(\displaystyle \frac{{\rm{\Delta }}\nu }{1\ \mathrm{GHz}}\right)}^{-1},\end{array}\end{eqnarray} \tag{ 7 }$$

where γ is the Lorentz factor of the pulsar wind, Δν is the emission bandwidth, D is the luminosity distance, P_⋆ is the spin period of the pulsar. In Equation (7), A_cone = 4π/Ω_A is an indication of the beaming factor. The radio waves are emitted into a solid angle Ω_A in the source frame, which could be nearly isotropic. Note, however, that the radiation is limited in a solid angle (Ω_A/4)γ⁻² in the observer's reference frame due to the beaming effect; the observer can see the FRBs only when the radio beams point toward the observer.

As described in Section 2, the orbits of the disrupted clumps will change due to dynamical interactions. Here, for simplicity, when studying their interaction with the pulsar wind, we only consider their first round of motion in the orbit. We further assume that the orbit is similar to that of the original planet. Using the orbital parameters constrained from the partial disruption condition, we can estimate the peak flux of the FRB generated due to the interaction of a clump and the pulsar wind through Equation (7). As an example, we have applied our model to FRBs 180916 and 121102. In our calculations, we take Ω_A = 0.1 sr, γ = 3 × 10⁶, and _r = 10⁻². Figure 3 shows the flux variation versus the orbital phase, which is caused by the variation of the distance r between the NS and the clump due to the large orbital eccentricity. Panel (a) of Figure 3 shows the effect of P_orb on the flux density. It is clear that the flux density is quite insensitive to P_orb under the partial disruption condition. Panels (b)–(d) of Figure 3 show the effects of B_⋆ and R_c on S for fixed P_orb and P_⋆. From these plots we can see that the effects of B_⋆ and R_c are significant. Note that for many parameter sets, S is larger than the detection threshold (0.3 Jy) during a significant portion of the orbital phase.

Zoom In Zoom Out Reset image size

In a typical duty circle, the observed FRB number is of the order of a few. This indicates that usually only a few major fragments are generated during the passage of the periastron. For the clump–wind interaction mechanism, the required size of the small body that can produce FRBs is a few kilometers. This is quite typical for the fragments generated during a partial disruption. Simulations show that the tidal disruption of a planet by a compact star such as a WD can give birth to fragments ranging from a few kilometers to ∼100 km (Malamud & Perets 2020a, 2020b). It is interesting to note that the number of observed bursts is related with fluence as N ∝ F^α+1, where α = −2.3 ± 0.3 for FRB 180916 (Chime/Frb Collaboration et al. 2020). So, there are many more low-fluence FRBs as compared with high-fluence ones. This is consistent with our NS–planet interaction model. In the partial disruption process, the number of smaller clumps is usually larger than that of bigger fragments (Malamud & Perets 2020a, 2020b).

4.1. Periodicity

Observations indicate that FRB 180916 seems to have a repeating period of 16.35 days (Chime/Frb Collaboration et al. 2020), while FRB 121102 may have a period of 157 days (Rajwade et al. 2020). This suggests that the periods of repeating FRBs may vary in a relatively wide range. In our model, the period is mainly determined by the orbital motion of the planet. The observed periods thus exert some constraints on the parameters of our NS–planet systems. Here we show that the planet-disruption model can meet the observational requirements.

As mentioned in Section 2, we take r_p = 2 r_td as the typical case for the partial disruption condition. This naturally leads to a relation of

$$\begin{eqnarray}&&a\left(1-e\right)=2{\left(\displaystyle \frac{6{M}_{\star }}{\pi \,\bar{\rho }}\right)}^{1/3}.\end{eqnarray} \tag{ 8 }$$

Combining Equations (1) and (8), one can derive the relationship between various parameters of the NS–planet systems. In Figure 4, we plot the relation between the eccentricity and orbital period for planets that satisfy the partial disruption condition. The calculations are conducted for planets with a mean density $\bar{\rho }=3\,{\rm{g}}\,{\mathrm{cm}}^{-3}$, 5 g cm⁻³, and 10 g cm⁻³, respectively. We can see that with an increase of the period, the eccentricity should also increase. This is easy to understand. The key point is that the periastron distance (r_p = 2 r_td) is almost fixed by the mean density in our framework. At the same time, to acquire a long orbital period, the semimajor axis should be large enough. As a result, the eccentricity will have to be large. From Figure 4, we can see that to get a period of ∼1 day, an eccentricity of e ∼ 0.3–0.5 is enough. However, to achieve a period of ∼16 days, e ∼ 0.9 will be required, while for P_orb ≥ 160 days, e ≥ 0.97 is necessary. In general, Figure 4 demonstrates that partial disruption does can happen periodically under proper conditions, and repeating FRBs with periods ranging from ∼1 to ∼1000 days are possible.

Zoom In Zoom Out Reset image size

4.2. Active Window

In the context of the Alfvén wing mechanism, the active window of FRBs is determined by the distribution of clumps in the orbit. The clumps originating from different parts of the planet have slightly different orbital parameters. The semimajor axis of the clumps disrupted from a planet around a WD is given in Malamud & Perets (2020a). Here, we applied it to our model as

$$\begin{eqnarray}\begin{array}{c}{a}^{{\rm{{\prime} }}}=\left\{\begin{array}{ll}a{\left(1+a\displaystyle \frac{2R}{d(d-R)}\right)}^{-1}, & ({\rm{In}}\,{\rm{the}}\,{\rm{direction}}\,{\rm{of}}\,{\rm{the}}\,{\rm{NS}})\\ a{\left(1-a\displaystyle \frac{2R}{d(d+R)}\right)}^{-1}, & ({\rm{In}}\,{\rm{opposite}}\,{\rm{direction}}\,{\rm{of}}\,{\rm{the}}\,{\rm{NS}})\end{array}\right.,\end{array}\end{eqnarray} \tag{ 9 }$$

where a is still the planet's original semimajor axis, d is the distance between the pulsar and planet at the moment of breakup, and R is the displacement of the clump relative to the planet's mass center at the moment of breakup (R = 0 corresponds to the center of the planet). In the opposite direction of the NS, there is a critical displacement R_crit = d²/(2a − d). Particles with R < R_crit are bound while particles with R > R_crit are unbound to the planet (Malamud & Perets 2020a).

The semimajor axes of disrupted clumps are different since their displacements (R) are different (see Equation (9)). Hence, their velocities and orbital periods are also different. The orbital velocity can be calculated by υ = r ω, where $\omega ={(2\pi /{P}_{\mathrm{orb}})(1+e\cos \theta )}^{2}/{(1-{e}^{2})}^{3/2}$ (Sepinsky et al. 2007). Substituting r with Equation (2), we get

$$\begin{eqnarray}&&{\upsilon }^{2}=\displaystyle \frac{G({M}_{\star }+m)}{a}\displaystyle \frac{{\left(1+e\cos \theta \right)}^{2}}{(1-{e}^{2})}.\end{eqnarray} \tag{ 10 }$$

This is the velocity of the planet at phase θ. We can further obtain the velocity of the disrupted clumps by substituting a in Equation (10) with ${a}^{{\prime} }$ of Equation (9).

The active window of the wind interaction mechanism is determined by the difference of the orbital periods of the clumps in the innermost and outermost orbits, which themselves can be obtained by combining Equations (9) and (1). Here, we assume that the line of sight lies in the orbital plane. In our calculations, for simplicity, we assume that the clumps are disrupted from the surface of the planet (i.e., $R={R}_{{\rm{c}}}={(3m/4\pi \bar{\rho })}^{1/3}$) at the periastron d = r_p = 2r_td. As an example, we take a planet's parameters as P_orb = 100 days, m = 10⁻⁶ M_⊙, and $\bar{\rho }=5\,{\rm{g}}\,{\mathrm{cm}}^{-3}$ (correspondingly, e = 0.971). The orbital velocity of such a planet at the periastron is 423.5 km s⁻¹. The velocity of the clumps in the outermost orbit is 389.5 km s⁻¹, corresponding to an orbital period of ${P}_{\mathrm{orb}}^{\mathrm{out}}=128.5$ days. For the clumps in the innermost orbit, the velocity is 455.1 km s⁻¹, corresponding to an orbital period ${P}_{\mathrm{orb}}^{\mathrm{in}}=80.6$ days. We can see that the difference of their orbital periods is 47.9 days. Below, we will consider the active windows of FRBs 180916 and 121102 in more detail.

The repetition period of FRB 180916 is 16.35 days and the active window is about 5 days. Figure 5 shows the period difference for the clumps in the innermost and outermost orbits as a function of the eccentricity and density. Under the partial disruption condition, a planet with m = 10⁻⁵ M_⊙ and P_orb = 16.35 days can produce clumps with period differences ranging from 4 to 6.25 days when the density ranges from $\bar{\rho }=3\,{\rm{g}}\,{\mathrm{cm}}^{-3}$ to $\bar{\rho }=10\,{\rm{g}}\,{\mathrm{cm}}^{-3}$. In these cases, the velocity of the planet is 429.7 km s⁻¹ at the periastron. The velocity of the clumps in the outermost orbit is 406.4 km s⁻¹, corresponding to an orbital period ${P}_{\mathrm{orb}}^{\mathrm{out}}=19$ days. For the clumps in the innermost orbit, the velocity is 451.9 km s⁻¹ and the orbital period is ${P}_{\mathrm{orb}}^{\mathrm{in}}=14$ days. The period difference is 5 days, which can satisfactorily meet the requirement of the observed active window of FRB 180916.

Zoom In Zoom Out Reset image size

The repetition period of FRB 121102 is about 157 days, and the active window is ∼87 days. Figure 6 shows the period difference for the clumps in the innermost and outermost orbits as a function of the eccentricity and density. Under the partial disruption condition, a planet with m = 5 × 10⁻⁷ M_⊙ and P_orb = 157 days can produce clumps with period differences ranging from 65 days to about 105 days when the density ranges from $\bar{\rho }=3\,{\rm{g}}\,{\mathrm{cm}}^{-3}$ to $\bar{\rho }=10\,{\rm{g}}\,{\mathrm{cm}}^{-3}$. In these cases, the velocity of the planet is 437.57 km s⁻¹ at periastron. The velocity of the clumps in the innermost orbit is 474.6 km s⁻¹, corresponding to an orbital period ${P}_{\mathrm{orb}}^{\mathrm{in}}=123.06$ days. For the clumps in the outermost orbit, the velocity is 397.28 km s⁻¹ and the orbital period is ${P}_{\mathrm{orb}}^{\mathrm{out}}=209.78$ days. The period difference is 86.72 days. Again it can satisfactorily meet the requirement of the observed active window of FRB 121102.

Zoom In Zoom Out Reset image size

Note that the gravitational perturbations from the planet itself still could influence the orbits of the clumps. Such perturbations can lead to changes in the inclination and eccentricity of the clump orbits so that the clumps will finally deviate from the line of sight. As a result, FRBs could be observed only from newly generated fragments, which maintains the periodicity and active window of the repeating FRBs. Below, we present more details on this issue.

In a triple system where a test particle revolves around its host in a close inner orbit while a third object moves around in an outer orbit, the eccentricity of the test particle can be significantly altered by the outer object. This is called the Kozai–Lidov effect, which can change the orbit of the test particle (Kozai 1962; Lidov 1962; Naoz 2016). In a normal Kozai–Lidov mechanism, the bigger planet's orbit is usually assumed to be circular and the vertical angular momentum is conserved for the test particle. As a result, the eccentricity and inclination of the test particle's orbit vary periodically. However, when the planet's orbit is eccentric, the z-component of the inner and outer orbits' angular momentum is not conserved, which leads to very different behaviors of the test particle (Lithwick & Naoz 2011; Li et al. 2014; Naoz et al. 2017). It was found that for a nearly coplanar (the inclination i ∼ 0) and highly eccentric (for both inner and outer) configuration, the eccentricity of the test particle increases steadily, while the inclination i oscillates in a small range (Li et al. 2014). It was also found that, for a system with a tight-orbit configuration, the perturbation is strong and the orbit of the test particle can be altered on short timescales.

In our model, as mentioned above, the clumps coming from different parts of the planet move in slightly different orbits as compared with that of the planet. These orbits are approximately coplanar and close to each other. The surviving major portion of the planet can create perturbation. Unlike the case of Li et al. (2014), our system breaks the secular approximation condition. Such a case has been discussed by Antonini et al. (2014). They found that the inclination and eccentricity of the test object still could change in a short time. As a result, in our cases, the direction of the Alfvén wing and the FRB emission cone will deviate from our line of sight in a short time (e.g., after one or two orbital periods) due to the inclination change. No FRBs would be observed from older fragments.

To summarize, in our framework, the line of sight lies in the original orbital plane of the planet. The clumps generated during the partial disruption process near the periastron will pass through the observer's line of sight one by one during their first round of motion in their new orbits, producing FRBs detectable by the observer. After that, the gravitational perturbation from the planet will change the orbits of the fragments so that they will no longer produce visible FRBs later. In other words, only new clumps generated near the periastron will produce FRBs. In this way, the periodicity and active window of the repeating FRBs can be well maintained.

For a planet composed of ordinary matter orbiting around a pulsar, the evaporation timescale at a fixed distance is (Kotera et al. 2016)

$$\begin{eqnarray}\begin{array}{rcl}{t}_{\mathrm{ev}} & = & 7.2\times {10}^{-12}\,\mathrm{yr}{\left(\displaystyle \frac{{R}_{{\rm{c}}}}{\mathrm{km}}\right)}^{3}{\left(\displaystyle \frac{\bar{\rho }}{{\rm{g}}\,{\mathrm{cm}}^{-3}}\right)}^{2}\\ & & \times \,{\left(\displaystyle \frac{r}{{R}_{\odot }}\right)}^{2}\displaystyle \frac{1}{{L}_{{\rm{p}},35}{Q}_{\mathrm{abs}}},\end{array}\end{eqnarray} \tag{ 11 }$$

where ${L}_{{\rm{p}}}=9.6\times {10}^{34}\,\mathrm{erg}\,{{\rm{s}}}^{-1}{I}_{45}{P}_{\star ,-3}^{-4}{B}_{\star ,8}^{2}{R}_{\star ,6}^{6}$ is the spin-down luminosity of the pulsar (here the convention Q_x = Q/10^x in cgs units is adopted), and Q_abs is the energy-absorption efficiency. Usually, Q_abs = 3/N_r for large planets and ${Q}_{\mathrm{abs}}=12x/{N}_{{\rm{r}}}^{2}+2{x}^{3}{N}_{{\rm{r}}}^{2}/15$ for small objects. Here, the refractive index is ${N}_{{\rm{r}}}=\sqrt{\mu \sigma {P}_{\star }}$, with μ σ = 10⁶ s⁻¹, and the size ratio is defined as x = R_c/cP_⋆. Taking P_⋆ = 1 s and B_⋆ = 10¹² G, the evaporation timescale is t_ev ∼ 10⁴ yr for a small object with a density $\bar{\rho }=3\,{\rm{g}}\,{\mathrm{cm}}^{-3}$ in a circular orbit r ∼ 10¹¹ cm (Kotera et al. 2016). However, the situation is very different for an object in a highly eccentric orbit, because the distance of the two objects varies in a very wide range. More importantly, for most of the time of each orbital cycle, the planet is far away from the pulsar. In our model, the periastron distance is ∼10¹¹ cm, but the average separation in one orbital period is much larger than this value. In the case of an elliptical orbit, the mean separation between the two objects is $\bar{r}=\tfrac{2}{{P}_{\mathrm{orb}}}{\int }_{0}^{{P}_{\mathrm{orb}}/2}{rdt}$ and can be calculated as

$$\begin{eqnarray}&&\bar{r}=\displaystyle \frac{a{\left(1-{e}^{2}\right)}^{5/2}}{\pi }{\int }_{0}^{\pi }\displaystyle \frac{1}{{\left(1+e\cos \theta \right)}^{3}}d\theta .\end{eqnarray} \tag{ 12 }$$

Substituting r in Equation (11) with $\bar{r}$, we can estimate the evaporation timescale of a planet in an elliptical orbit. In our model, assuming m = 10⁻⁵ M_⊙, P_orb = 16.35 days, and $\bar{\rho }=3\,{\rm{g}}\,{\mathrm{cm}}^{-3}$, then the planet will be partially disrupt when e = 0.88. In this case, the evaporation timescale can be derived as t_ev = 2 × 10⁷ yr. If the mean density is taken as $\bar{\rho }=10\,{\rm{g}}\,{\mathrm{cm}}^{-3}$, then it will be partially disrupted when e = 0.92, and the evaporation timescale correspondingly becomes t_ev = 7 × 10⁷ yr. If we take the pulsar spin period as P_⋆ = 1 s, then we get t_ev = 6.3 × 10¹¹ yr for $\bar{\rho }=3\,{\rm{g}}\,{\mathrm{cm}}^{-3}$, and t_ev = 2.2 × 10¹² yr for $\bar{\rho }=10\,{\rm{g}}\,{\mathrm{cm}}^{-3}$. A planet with m = 10⁻⁵ M_⊙, P_orb = 157 days, and $\bar{\rho }=3\,{\rm{g}}\,{\mathrm{cm}}^{-3}$ will be partially disrupted when e = 0.975, corresponding to an evaporation timescale t_ev = 4.6 × 10⁸ yr. If the mean density is taken as $\bar{\rho }=10\,{\rm{g}}\,{\mathrm{cm}}^{-3}$, then it will be partially disrupted when e = 0.983, corresponding to an evaporation timescale t_ev = 1.5 × 10⁹ yr. If we change the pulsar spin period to P_⋆ = 1 s, then we get t_ev = 1.6 × 10¹³ yr for $\bar{\rho }=3\,{\rm{g}}\,{\mathrm{cm}}^{-3}$, and t_ev = 4.9 × 10¹³ yr for $\bar{\rho }=10\,{\rm{g}}\,{\mathrm{cm}}^{-3}$. From the above calculations, we can see that the evaporation timescale of a planet in our elliptical orbit is generally very large. Therefore, the effect of evaporation is negligible in this framework.

In Section 3, we demonstrated that to account for the observed repeating FRB periods ranging from tens of days to over one hundred days, a highly elliptical planet orbit with e ≥ 0.9 is needed. It is a natural question that whether such highly elliptical orbits are possible or not for planets. Here we present some discussion on this issue.

Since the discovery of the first extrasolar planet around PSR 1257+12 (Wolszczan & Frail 1992), about 4700 exoplanets (as of 2021 April 27) have been discovered (see Extrasolar Planets Encyclopaedia—EU ⁹ ; Schneider et al. 2011). Among them, more than 10 objects are pulsar planet candidates. Although the eccentricities of these pulsar planet candidates are generally very small, high-eccentricity pulsar binaries have been discovered (see references in the databases "Pulsars in globular clusters" ¹⁰ and The ATNF pulsar catalog ¹¹ ; Manchester et al. 2005). Additionally, a few planets with large eccentricities orbiting around other types of stars have also been detected (see the EU database). Good examples for these include HD 20782 b (e = 0.97 ± 0.01), HD 80606 b (e = 0.93366 ± 0.00043), HD 7449 A b (e = 0.92 ± 0.03), and HD 4113 A b (e = 0.903 ± 0.005). The existence of these special planets indicates that the formation of high-eccentricity planetary systems around compact objects should also be possible. Planets with a large eccentricity could be formed around a NS through at least three channels. First, a free-floating planet (FFP) can be captured by a NS when they are in a close encounter. Second, exchange/snatch of a planet may happen between a NS and a nearby main-sequence planetary system. Third, the Kozai–Lidov effect in a multibody system may give birth to a high-eccentricity planet. Below, we discuss these three processes briefly.

• 1.
  Formation from the capture of FFPs by NS:FFPs are common in space (Smith & Bonnell 2001; Hurley & Shara 2002; Sumi et al. 2011; van Elteren et al. 2019; Johnson et al. 2020; Mróz et al. 2020). They may be formed from various dynamical interactions (see Figure 1 in Kremer et al. 2019), such as ejection from dying multiple-star systems (Veras & Tout 2012; Wang et al. 2015; van Elteren et al. 2019), planet–planet scattering (Hong et al. 2018; van Elteren et al. 2019), or the encounter of a star with other planetary systems (Hurley & Shara 2002). In a cluster's full lifetime, about 10%–50% of primordial planetary systems experience various dynamical encounters and many planets become FFPs. About 30%–80% of them escape the cluster due to strong dynamical encounters and/or tidal interactions (Kremer et al. 2019) and travel freely in space. The velocity of these FFPs is typically in the range of 0–30 km s⁻¹ (Smith & Bonnell 2001; Hurley & Shara 2002). FFPs may be captured by other stars or planetary systems and form highly eccentric planetary systems (Parker & Quanz 2012; Wang et al. 2015; Li & Adams 2016; Goulinski & Ribak 2018; Hands et al. 2019; van Elteren et al. 2019). A simulation by Goulinski & Ribak (2018) showed that more than 99.1% of the captured planets are in an orbit with e > 0.85, and the masses of FFPs do not affect the eccentricity significantly.
• 2.
  Formation from NS exchange/snatch a planet:Pulsars can obtain a kick velocity when they are born in the supernova explosion. If a planet survives in supernova, the newborn high-speed pulsar and the surviving planet may form an eccentric planetary system by gravitational interaction. Additionally, when a pulsar moves with a kick velocity of 100–400 km s⁻¹ in space, it may pass by a planetary system. During this process, the pulsar can also exchange/snatch a planet from other planetary systems via gravitational perturbations. Planetary systems formed in this way may also be eccentric.
• 3.
  Formation from the Kozai–Lidov effect in a multibody system:The Kozai–Lidov effect (Kozai 1962; Lidov 1962; Naoz 2016) can explain the dynamics of multibody systems in which one companion in an outer orbit can change (increase) the eccentricity of objects in inner orbits by gravitational perturbations. The timescale for forming a high-eccentricity system is determined by the initial parameters. If the central star of such a multibody system is a NS then a highly eccentric NS–planet system may form.

From the above descriptions, we can see that there are many routes to form high-eccentricity planets around NSs. The requirement of e ≥ 0.9 in our framework thus in principle can be met in reality.

Here, we roughly calculate the population of highly eccentric planetary systems in the the Milky Way. It is estimated that there are 100–400 billion stars in our Galaxy (see the Universe Today ¹² and NASA ¹³ websites). A study based on microlensing observations suggests that each star hosts 1.6 planets on average (Cassan et al. 2012). Taking 200 billion as the rough number of stars, then there would be about 320 billion planets in the the Milky Way. Since about 10%–50% of primordial planetary systems experience various dynamical encounters and produce FFPs, as mentioned above (Kremer et al. 2019), it is expected that there should be 20–100 billion FFPs in the whole Galaxy. More than 85% of the stars in the Galactic disk are in a mass range of 0.1 M_⊙ < M < 2 M_⊙. About 1% of them are expected to experience at least one capture process during their lifetime (Goulinski & Ribak 2018). This allows us to estimate that there are 1.7 billion captures and 99.1% (1.68 billion) of them give birth to planets in a highly eccentric orbit with e > 0.85. Currently, four highly eccentric (e > 0.9) planets have been confirmed among the observed 4700 planets, corresponding to a fraction of 0.085%. Using this ratio as a reference, it can be estimated that the number of highly eccentric (e > 0.9) planetary systems in our Galaxy is ∼170 million. From the above analysis, we can see that highly eccentric planetary systems are copious in the the Milky Way. However, it is not easy to detect them due to various observational biases. For these planets, the evaporation again can be safely omitted since the timescale is usually much more than 10⁷ yr.

In this study, we aimed to explain the periodic repeatability of FRBs by considering a NS–planet interaction model. In our framework, a planet moves around its host NS in a highly eccentric orbit. The periastron of the planet satisfies a special condition r_td ≤ r_p ≤ 2 r_td, so that the crust of the planet will be partially disrupted every time it pass through the periastron. Fragments with the size of a few kilometers are produced in the process. During this process, the fragments interact with the pulsar wind via the Alfvén wing mechanism to give birth to FRBs. The periods of repeating FRBs correspond to the orbital periods of the planets. To account for the observed periods of ∼10–100 days, an orbital eccentricity larger than ∼0.9 is generally required. It is shown that the basic features of two well-known repeating sources, FRBs 121102 and 180916, can be satisfactorily interpreted by the model.

It is interesting to note that the interaction of small bodies with NSs has already been studied to interpret repeating FRBs, but generally in a very different framework. For example, Dai et al. (2016) explained repeating FRBs as due to the multiple collisions that happen when a NS travels through an asteroid belt. Decoene et al. (2021) even suggested a three-component scenario which involves a NS, an asteroid belt around it, and a third outer companion. In their model, the outer companion can be a black hole, a NS, a WD, or a main-sequence star. While our model is in principle different, we would like to point out that some ingredients in the above models may also play a role in our model. For example, when the fragments finally arrive at the NS and collide with it, FRBs may be produced via the NS–asteroid collision mechanism (Geng & Huang 2015; Dai et al. 2016). Yet, the time needed for the clumps to fall into the NS is highly uncertain and still needs to be further studied. Note that the disruption distance of rocky planets is ∼10¹¹ cm (Mottez et al. 2013a, 2013b). At this distance, the evaporation takes a time of only ∼10⁴ yr (Kotera et al. 2016). However, the ellipticity of the orbit can prolong the evaporation timescale by several orders of magnitude, to ≥10⁷ yr. Therefore, the evaporation does not affect our model significantly.

We would like to thank the anonymous referee for helpful suggestions that led to significant improvement of our study. This work is supported by the special research assistance project of the Chinese Academy of Sciences (CAS), by the National Natural Science Foundation of China (grant Nos. 12041306, 12041304, 11873030, U1938201, U1838113, U2031209, 11903019, 11833003, 12033001, 12103055), by the National Key R&D Program of China (grant No. 2021YFA0718500), by the National SKA Program of China (grant No. 2020SKA0120300), by the CAS "Light of West China" Program (grant No. 2018-XBQNXZ-B-025), by science research grants from the China Manned Space Project with No. CMS-CSST-2021-B11, and by the Operation, Maintenance and Upgrading Fund for Astronomical Telescopes and Facility Instruments, budgeted from the Ministry of Finance of China (MOF) and administrated by the CAS. This work is also partially supported by the Strategic Priority Research Program of the CAS under grant No. XDA15360300.

Software: SciPy (Virtanen et al. 2020), Matplotlib (Hunter 2007), NumPy (van der Walt et al. 2011).
