DISCOVERY OF A NEW CLASS OF CORONAL STRUCTURES IN WHITE LIGHT ECLIPSE IMAGES

The naked-eye impression of the corona during a total solar eclipse is that of rays expanding in all directions from the solar surface, out to several solar radii. First captured in drawings, and subsequently with photography in the late 1800s, these impressions defined what we currently call "coronal structures." The most prominent rays emanate from the polar regions; they are ubiquitous throughout most of the solar cycle, with the exception of maximum sunspot activity. Streamers, characterized by bulges at their base and tapering off to thin rays with radial distance, become the dominant component at maximum solar activity. To the eye, the extent of the white light emission from the corona seems to be much larger at solar minimum than at solar maximum. Prominences, distinguished by their pinkish hue, invariably stand out during totality, irrespective of the time within a sunspot cycle. They are often considered by many eclipse chasers to be the highlight of the event.

The white light emission observed during total solar eclipses is a consequence of the scattering of photospheric emission by free electrons in the corona. Hence, the structures captured in eclipse images are not only tracers of the distribution of coronal electron density, but are also directly associated with coronal magnetic fields and outline their direction. The radial span and shape of these structures thus laid the foundation for models of the coronal magnetic fields (e.g., Munro & Jackson 1977). With the continued absence of direct measurements of coronal magnetic fields, eclipse images continue to serve as drivers as well as verifications for steady-state models of the corona and solar wind (e.g., Wang et al. 2007; Ambrož et al. 2009; Rušin et al. 2010; Antiochos et al. 2012).

However, the coronal plasma is far from static. It has to respond to turbulent motions associated with magnetic flux emergence leading to reconnection on all scales across the solar surface, to the production of MHD waves and to disturbances on much larger scales, such as filament eruptions and coronal mass ejections (CMEs). Despite their short duration (ranging from seconds to a maximum theoretical time of 7.15 minutes), and their paucity (occurring once every one to two years), eclipse observations are well suited for studies of coronal dynamic events. Indeed, historical records show that a CME, albeit not recognized as such at the time, was recorded in an eye-witness image by A. Secchi during the eclipse of 1860 July 18 observed from Torreblanca, Spain. More recent eclipse observations captured the aftermath of the passage of CMEs in the inner corona (Habbal et al. 2011), and the development of an active region (Pasachoff et al. 2006). Observations of a given eclipse from different observing sites, separated by minutes to several hours, can also lend clues to dynamic events on those timescales. For example, the brightening of a polar plume was documented during the 2006 March 29 total solar eclipse from observations at two sites separated by 30 minutes (Pasachoff et al. 2008).

We show in this work how eclipse observations, described in Section 2, continue to yield novel insights into structures defining the coronal plasma and magnetic field despite the proliferation of space-based white light coronagraph observations of the extended corona and extreme-ultraviolet (EUV) observations very close to the Sun. In particular, we highlight the ubiquitous presence of smoke or vortex rings, expanding bubbles, nested loops, and twisted helical structures, mostly hitherto unknown (Section 3). Some of these structures seem to have counterparts in recently reported EUV observations very close to the Sun, and in white light coronagraph images beyond 2 R_☉. Others remain unique to eclipse images, at present, although their occurrence seems to be validated by model studies and plasma laboratory experiments (Section 4). We conjecture that these newly discovered features originate at every prominence–corona interface and that the eclipse images capture snapshots of the different evolutionary stages of the ensuing instabilities. We briefly discuss their implications for the evolution of the solar wind (Section 5).

The white light eclipse data shown in Figures 1–3 are from our most recent observations of 2010 July 11, 2009 July 22, and 2008 August 1, respectively. They coincide with the beginning (2008) and the rising phase of solar activity cycle 24. The spatial resolution in these images is 2''–3''. (See Habbal et al. 2010, 2011; Pasachoff et al. 2009, for more technical details regarding the acquisition of these data.) In addition, an example from the 2001 June 21 eclipse (Figure 4) taken from Angola at the peak of magnetic activity cycle 23, was selected for two reasons. (1) To show that the new class of structures, which will be described next, is ubiquitous in the corona even with observations taken with film and subsequently digitized, and (2) to explore whether their appearance has any solar cycle dependence.

Zoom In Zoom Out Reset image size

The observations reported here were taken with Canon digital cameras (with the exception of Figure 4) with different focal length lenses. Details of the optics are described in the corresponding captions of Figures 1–4. In Figures 1–3, the full field of view of the corona is shown at the top, and close-up details within the outlines of the rectangles are given below.

Typically during totality, a sequence of at least 10 or more exposures is needed to cover the dynamic range of the coronal white light emission out to a few solar R_☉. The application of sub-pixel alignment of images taken with different exposure times, a technique recently developed by Druckmüller (2009), as well as the application of the recently developed image processing technique referred to as the Adaptive Circular High-pass Filter (ACHF; Druckmüller et al. 2006), enable the creation of a single composite image with a resolution of 2''–3''. In general, the total effective exposure time needed for each image ranges from 20 to 50 s. The resulting composites expose the solar atmosphere starting from the upper chromosphere out to a distance of several solar radii all around the Sun. The lower chromosphere, down to the photosphere, near the east and west limb (Figures 1–4) may be exposed as well because these parts of the corona are progressively visible during any total solar eclipse. Observing the lower chromosphere near the northern and southern solar limb is complicated because it is either necessary to observe from locations near the edge of the shadow band of totality or the shadow band itself must be very narrow. In the both cases, the total eclipse is very short, on the order of a few seconds in duration.

Application of the ACHF to white light eclipse images also enables the enhancement of high spatial frequencies by about a factor of 300, such that structures with contrast 10³ times fainter than the global contrast in an image becomes visible. Furthermore, this technique has the marked advantage of capturing faint structures within the context of the background "quiescent" large-scale coronal structures. Typically, dynamic or time-varying events, such as CMEs, are much fainter than the quiescent structures. CMEs were originally discovered with the space-based coronagraph on Skylab in the early 1970s using a simple running difference technique (e.g., Gosling et al. 1974). Such an approach is straightforward when a time sequence of observations spanning several hours is available. Recently, alternative techniques have been developed to expose faint dynamic structures, whereby a background, or quiescent corona, is defined and subtracted from a time sequence of images (e.g., Morgan et al. 2006, 2012). However, with such techniques, the dynamic structures are exposed while structures in the quiescent background corona are significantly reduced. Furthermore, such techniques are not applicable to eclipse observations since they rely on the availability of observations with extended time sequences. We demonstrate in what follows how the faint structures captured in eclipse images with the application of the ACHF are snapshots of non-stationary events, some of which were hitherto unknown.

In the examples of the ACHF processed white light images shown in Figures 1–3, the corona is invariably dominated by ray-like structures. The most streamlined ones fill the polar regions. Away from the poles, these rays outline the shapes of streamers with arch-like structures defining their base. In Figure 4, taken at the peak of solar activity, the polar regions are indistinguishable from the rest of the corona, with streamers, loops, and rays distributed almost uniformly around the Sun. However, regardless of the time period within the solar activity cycle, a variety of features, clearly distinct from rays and streamers, with some significantly fainter, are invariably present in these eclipse images. In what follows, an attempt is made to classify them following some common characteristics.

3.1. Small-scale Loops and Vortex or Smoke-like Rings

3.2. Nested Loops

3.3. Expanding Bubbles

Further away from the limb, a background of very faint and low contrast expanding bubbles, seemingly propagating away from the Sun, is clearly discernible and distinct from the large-scale nested loops. These are indicated by arrows 1, 2, and 3 in Figures 2(A) and 2(B). The most striking examples appear in Figure 3(A), with arrow 2 pointing to one example. The bubbles exhibit some structural coherence, and/or self-similarity, in a manner similar to that exhibited by the nested loops. They seem to form a faint background, filling a significant fraction of the corona, over at least a distance range of 1 R_☉, especially at the minimum of solar activity, such as in 2009 (Figure 2) and 2008 (Figure 3).

Zoom In Zoom Out Reset image size

Zoom In Zoom Out Reset image size

3.4. Twisted Helical Structures and Turbulence-like Structures

On a somewhat larger scale, we note the presence of twisted helical structures spanning a distance range of at least 0.5–1 R_☉. The most prominent examples are present all around arrow 2 in Figure 1(A). An example is also visible in Figure 2, indicated by arrow 4. Note that these two examples are visually different, most likely representing the same type of structure viewed from different perspectives.

There is also a preponderance of turbulence-like structures in the eclipse images. One example is indicated by arrow 1 in Figure 3, and another is within the rectangle of Figure 4. Another example which could be equally interpreted as a twisted helical structure as well as a propagating turbulent structure appears at the west boundary of the south polar coronal hole, enclosed within the rectangle labeled C in Figure 1.

Zoom In Zoom Out Reset image size

3.5. Impact of the Solar Cycle

The examples presented above document the ubiquitous presence of a class of structures clearly distinct from the background corona of rays and streamers. Close to the Sun, the small-scale nested loops, as well as the vortex rings, typically 20''–30'' in height, are comparable in brightness to the background corona in these images. On the other hand, the large-scale nested loops, bubbles, and twisted helical structures are about two to three orders of magnitude fainter, and extend out to several solar radii above the limb. The impression one gets from the latter features is that of dynamic events, expanding away from the solar surface. Undoubtedly, if these features are dynamic, then they must be related to known dynamic structures at the Sun. Prominences are the prime candidate: when observed in projection off the limb, they exhibit continuous rising, falling and twisting motions, with counter-flows running along their complex magnetic structures. Their most violent eruptions lead to CMEs.

We argue in what follows that the class of structures detected in the white light eclipse images are inherently associated with the dynamic behavior of prominences. They are a natural consequence of the prominence-corona interface between a cool and dense plasma embedded in a hot and tenuous background, with shear flows developing between them. The inevitable consequence for this interface is the development of instabilities, vortices, and turbulence in its immediate vicinity. The Earth's magnetopause is a prime example of a similar interface where the development of a Kelvin–Helmholtz (KH) instability and the formation of vortices have been observed (see, e.g., Hasegawa et al. 2004).

4.1. Nested Small-scale and Expanding Faint Loops

4.2. Vortex Rings, Twisted Helical Structures, and Expanding Bubbles: Evidence of Plasma Instabilities?

The observations presented here underline the main advantages of eclipse images in capturing snapshots of the coronal state, starting from the solar surface and spanning several solar radii outward. Tracking the dynamic evolution of small-scale structures and plasma instabilities originating in the inner corona, as they propagate outward, remains challenging. The EUV observations from AIA/SDO have an unmatched temporal and spatial resolution. Yet, they remain limited to the first 0.25 R_☉ above the surface due to the density square dependence of the emission. Unlike eclipse observations, the fate of dynamic structures as well as the appearance of dynamic events in the context of large-scale structures is excluded from EUV observations. On the other hand, the inner field of view of the best resolution space-based white light coronagraph at present, namely Solar and Heliospheric Observatory/LASCO C2, is blind to the first radius above the limb. Because of the light diffraction on the occulter it is impossible to build a coronagraph with an internal occulter that can provide images of the inner corona with the quality comparable to that attained with total solar eclipses. Hence, the origin of large-scale quiescent and dynamic structures at the Sun will remain inherently missing from the coronagraphic observations.

The unique observing conditions afforded by total solar eclipses, and the advent of state-of-the art image processing techniques, such as the ACHF, have made it possible to detect and capture the evolution of a plethora of structures within the context of the background corona. The absence of coronal observations, covering the distance range of eclipse images, are the most likely reasons why their preponderance has not previously been reported before. The presence of the new class of structures reported here cannot go unnoticed. They most likely reflect the different manifestations of plasma instabilities that inevitably arise in a complex magnetized plasma such as the corona.

We conjecture that the state of the corona reflects a spectrum of dynamic events. Some of these events are in the form of prominence eruptions and CMEs. Others are more subtle and form a continuum of faint structures such as the ones reported here. In fact, the structure of the corona, even on large scales in some cases, cannot be interpreted in terms of static structures. Indeed, static models of the corona (such as PFSS extrapolations) are limited in their scope due to the intrinsic dynamic nature of coronal structures.

It is plausible that this spectrum of dynamic events is the inevitable consequence of the development of instabilities at the prominence–corona interfaces that abound in the corona. Some supporting evidence can be gleaned from the observed difference between the structures captured at solar maximum in comparison to solar minimum and the rising phase of solar activity. At solar minimum (2009, Figure 2), there was an abundance of faint rising bubbles and nested loops. No vortices were captured at that time. At the other extreme, at solar maximum (2001, Figure 4), there was a plethora of vortices and turbulence-like structures around the Sun. Polar-crown filaments, which essentially define the boundaries of polar coronal holes at the Sun, and the magnetic polarity inversion there, are known to be relatively stable in comparison with active region prominences. Coronal structures are much simpler in the polar regions, hence prominence–corona interfaces there are expected to be more stable; the presence of the large-scale nested loops and bubbles is evidence for the extension of large-scale loops above polar crown filaments. In contrast, the complexity of coronal structures at solar maximum is such that prominence–corona interfaces, in particular within active regions, are bound to be prone to instabilities, hence the proliferation of vortex rings.

At present, the complexity of coronal structures, as presented in the examples given here, does not factor in MHD models of the corona. An example of the importance of this complexity can be inferred from Figure 5 of Riley et al. (2012). These authors show how the complexity of the current sheet in their simulation increases significantly with the spatial resolution of their computational grid, in particular the appearance of spiraling structures near the equator, and the complicated boundary between the polar coronal holes and mid-latitudes. While their model is not directly related to vortex rings or the small-scale features we are reporting here, their example illustrates that simulations cannot at the moment account for the complexity at small scales, which are ubiquitous in the corona. Hence, at present, much is lost in simulations when one is attempting to understand the role of small-scale structures.

We should also caution that white light coronal images, like all remote sensing imaging, show emission along an extended line of sight. Hence, the interpretation of fine- scale and faint structures cannot necessarily be considered unique. The complex appearance of the corona, particularly after the application of image processing which enhances smaller-scale and fainter features, can partly be attributed to the alignment of structures along the line of sight. For example, it would be difficult to distinguish a small flux rope viewed along the tube axis from a vortex ring. The only reliable way to discriminate between the two would be higher resolution and higher cadence white light observations of the lower corona than the ones presented here. At present, the different faint structures reported in these eclipse observations support the vortex ring interpretation and corresponding instabilities in favor of flux tubes.

As noted by M. Ryutova (2012, private communication), vortex rings have the interesting property whereby their energy increases as their radius expands with their propagation. Hence, their role in the solar wind flow warrants future exploration. Morgan (2013) also pointed out that the rising nested loops could be carrying material which eventually forms the slow solar wind. While studies of models of CMEs currently abound, it is timely to consider the impact of the much more prevalent prominence-corona dynamic interface on the solar wind flow.

We emphasize in closing that the main goal of this work is to unveil and report on the presence of coronal structures, which have not been observed in the past. We have provided one interpretation, namely, the occurrence of instabilities at the prominence–corona interface, starting with the formation of vortex rings. Its validation, or the validation of alternative interpretations, requires more data. Processing archived film eclipse images, which are one source that has not yet been tapped into, is planned for the future. There is no doubt that much modeling and theoretical work are needed as well to fully assess the impact of these new class of structures on our understanding of coronal dynamic structures and the solar wind.

M. Druckmüller was supported by Grant Agency of Brno University of Technology, project No. FSI-S-11-3. S. R. Habbal and H. Morgan acknowledge support from NASA Grant NNX08AQ29G and NSF grant ATM 08-02520 to the University of Hawaii. H. Morgan's work was conducted under funding by the Coleg Cymraeg Cenedlaethol. We wish to acknowledge fruitful discussions with M. Ryutova and R. Grappin.
